Advanced front air bags with seat belt-use, passenger-weight sensors
Front side-impact air bags and side-impact air curtains with rollover protection
3-point seat belts for all seating positions
Front seat belt pretensioners with force limiters
Anti-lock Brake System with Electronic Brake Force Distribution & Brake Assist
Dynamic Stability Control and Traction Control System
Hill Launch Assist
Advanced Blind Spot Monitoring with Rear Cross Traffic Alert
Mazda Radar Cruise Control with Stop & Go
Smart City Brake Support
Smart Brake Support
Lane Departure Warning with Lane-keep Assist
Side-impact door beams
Engine-immobilizer antitheft system
Tire Pressure Monitoring System (TPMS)
LATCH rear seat child safety seat anchors & upper tether anchors
Child safety rear door locks

2.0L
Engine type SKYACTIV®-G 2.0L DOHC 16-valve 4-cylinder petrol engine with i-stop <
Maximum power 115kW @ 6,000rpm/ Horsepower 154 hp @ 6,000 rpm
Torque 200Nm @ 4,000rpm/ Torque 137 lb-ft @ 4,000 rpm
Displacement (cc) 1998 Bore x stroke (mm) 83.5 x 91.2
Compression ratio 13.0 : 1 Fuel system Advanced Direct Injection
Recommended fuel Unleaded (91RON or higher) or E10
SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

2.5L
Engine type SKYACTIV®-G 2.5L DOHC 16-valve 4-cylinder with Cylinder Deactivation
Maximum power 139.4 kW @ 6,000 rpm / Horsepower 187 hp @ 6,000 rpm
Torque 252.1 Nm @ 4,000 rpm / Torque 186 lb-ft @ 4,000 rpm
Redline 6,500 rpm
Displacement (cc) 2488
Bore x stroke (mm) 89 x 100
Compression ratio 13.0 : 1
Fuel system Advanced Direct Injection
Recommended fuel Regular unleaded
Valvetrain Chain-driven dual overhead cams, 4-valves per cylinder with variable valve timing (VVT)
Ignition system Direct coil-on-plug electronic ignition with platinum-tipped spark plugs
Engine block Aluminum alloy
Cylinder head Aluminum alloy
SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

Type Front-wheel drive (FWD) or i-ACTIV AWD®
Automatic transmission SKYACTIV®-Drive 6-Speed automatic transmission with manual-shift and Sport mode

GEAR RATIOS (:1) Automatic Transmission
1st 3.552
2nd 2.022
rd 1.452
4th 1.000
5th 0.708
6th 0.599
Reverse 3.893
Final drive 4.325 (FWD) / 4.624 (AWD)

Brakes 4-wheel disc, diagonal hydraulic
- Front 297-mm vented disc
- Rear 302-mm solid disc
- ABS 4-wheel, 4-channel with Electronic Brake Force Distribution (EBD) and Brake Assist
Steering type Power rack-and-pinion with variable assist
Power assist Electronic Power Assist Steering (EPAS)
Overall steering ratio 15.5:1
Steering wheel turns, lock-to-lock 2.7
Turning circle diameter, curb-to-curb (m) 10.9
Suspension 4-wheel independent
- Front MacPherson strut with stabilizer bar
- Rear Multilink with stabilizer bar

Curb weight (kg) 1,616 (FWD) / 1,675.1 (AWD)
Towing Capacity (kg) 907.1
Fuel capacity (liters) 56 (FWD) / 57.9 (AWD)

Dual-zone automatic climate control with pollen filter
Rear air conditioning vents
Power sliding-glass moonroof with one-touch-open feature and interior sunshade
Power windows with driver's one-touch down/up feature
Speed sensitive power door locks with 2-stage unlocking
Mazda Advanced Keyless Entry and Start System
Auto-dimming rearview mirror with HomeLink®
Push Button Start Electronic parking brake
Dual covered illuminated visor vanity mirrors
Tilt & telescopic steering column
Map lights, Dome light and Cargo area light
Remote fuel-door release
Rear window defogger with timer

Overhead console with sunglasses holder
Center console armrest with tray and covered storage bin
Rear seat center armrest with integrated cup holders
Front and rear door bottle holders/storage
Driver and Front passenger seatback pockets

5-passenger seating capacity
8-way power driver's seat with power lumbar support and 2-position memory
6-way power front passenger seat 40/20/40 split one-touch fold-down and reclining rear seatback
Adjustable front and rear headrests
Heated front seats (3 levels)
Leather-trimmed seats
Leather-wrapped steering wheel
Leather-wrapped gear selector
Carpet floor mats

7" full-color touch screen display
Bose® 10-speaker audio system with Centerpoint® 2 and AudioPilot® 2
Bluetooth® hands-free phone and audio capability HD Radio™
Mazda Navigation System
Rearview Camera

MAZDA CONNECT™ Infotainment System
- Infotainment system voice command
- Multifunction Commander Control
- Radio Broadcast Data System program information
- Aha™ internet radio integration
- Pandora® internet radio integration
- Stitcher™ internet radio integration
- SMS text message audio delivery and reply

Auxiliary audio input jack
USB Inputs, 2 front and 2 rear
Steering wheel-mounted audio, phone and cruise controls

Speedometer, tachometer and fuel gauge, black background with white lettering and silver surround
Ambient temperature & clock display
Multi-Information Display (MID) with Trip computer

LED Headlights with Auto-leveling
LED Daytime Running Lights
LED fog lights
LED Combination taillights
Adaptive Front-lighting System
High Beam Control
Auto on/off headlights
Power Rear Liftgate with programmable height adjustment
Rain-sensing variable-intermittent windshield wipers I
ntermittent rear wiper/washer
Body-colored heated power side mirrors with integrated turn signals
Rear privacy glass
Roof-mounted "shark fin" antenna
Body-colored rear roof spoiler
Dual exhaust outlets with bright finish

Wheel size (cm) 48.26 x 17.78 aluminum alloy
Wheel size and type P225/55 R19 all-season tires
Temporary spare tire T145/90D16

Wheelbase (mm) 2,697
Track, front (mm) 1,595
Track, rear (mm) 1,521
Length (mm) 4,549
Width (mm) 1,842
Height (mm) up to roof, without roof rails, FWD/AWD 1,661 / 1,659
Height (mm) up to roof, without roof rails, up to sharkfin antenna
FWD/AWD 1,681 / 1,679
Minimum ground clearance - Unladen (mm) 190.5
