Advanced dual front air bags with passenger weight sensors (Mazda Advanced Restraint System)
Front seat-mounted side-impact air bags and side-impact air curtains
3-point safety belts for all seating positions
Headrests, adjustable - front & rear - all seating positions
Front safety-belt pretensioners with force limiters
Whiplash-reducing front seat headrests
Anti-lock Brake System (ABS) with Electronic Brake Force Distribution & Brake Assist
Hill Launch assist
Dynamic Stability Control (DSC) with Traction Control System (TCS)
Advanced Blind Spot Monitoring with Rear Cross Traffic Alert
Smart City Brake SupportRearview camera
SKYACTIV®-Body ring structure
Side-impact door beams
Collapsible steering column
Foldaway brake pedal assembly
Engine-immobilizer antitheft system
Keyless remote panic button (on key fob)
Automatic door locks (speed-sensitive and transmission-sensitive)
LATCH child safety seat anchors & upper tethers
Tire Pressure Monitoring System (TPMS)
Child safety rear door locks
Rear parking sensors

2.0L
Engine type SKYACTIV®-G 2.0L DOHC 4-cylinder with VVT
Maximum power 115.5 kW @ 6000 rpm / Horsepower 155.5 hp @ 6000 rpm
Torque 203.3 Nm @ 4000 rpm / Torque 150 lb-ft @ 4000 rpm
Redline 6800 rpm
Displacement (cc) 1998
Bore x stroke (mm) 83.5 x 91.2
Compression ratio 13.0:1
Fuel System Advanced Direct Injection
Recommended fuel regular unleaded
Valvetrain Chain-driven dual overhead cams, 4 valves per cylinder with variable intake valve timing (VVT)
Ignition system direct coil-on-plug electronic ignition with platinum-tipped spark plugs
Engine block aluminum alloy
Cylinder head aluminum alloy
Emission Control PZEV (Tier3Bin30)
SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

2.5L
Engine type SKYACTIV®-G 2.5L DOHC 4-cylinder with VVT
Maximum power 137.2 kW @ 5700 rpm / Horsepower 184 hp @ 5700 rpm
Torque 250.8 Nm @ 3250 rpm / Torque 185 lb-ft @ 3250 rpm
Redline 6500 rpm
Displacement (cc) 2488
Bore x stroke (mm) 89.0 x 100.0
Compression ratio 13.0:1
Fuel System Advanced Direct Injection
Recommended fuel regular unleaded
Valvetrain Chain-driven dual overhead cams, 4 valves per cylinder with variable intake valve timing (VVT)
Ignition system direct coil-on-plug electronic ignition with platinum-tipped spark plugs
Engine block aluminum alloy
Cylinder head aluminum alloy
SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

Type Front-wheel drive (FWD)
6-speed overdrive manual transmission SKYACTIV®-MT
6-speed automatic transmission SKYACTIV®-DRIVE with manual-shift mode and sport mode

Gear ratios (:1) 6 AT

1st 3.552
2nd 2.022
3rd 1.452
4th 1.000
5th 0.708
6th 0.599
Reverse 3.893
Final Drive 3.389

6 MT

1st 3.700
2nd 1.947
3rd 1.300
4th 1.029
5th 0.837
6th 0.680
Reverse 3.724
Final Drive 3.850

Brakes 4-wheel disc
- Front 295 mm vented disc
- Rear 265 mm solid disc
- ABS 4-wheel, 4-channel with Electronic Brake Force Distribution and Brake Assist
Steering type power rack-and-pinion with variable assist
Electronic Power Assist Steering (EPAS)
Overall steering ratio 14:1
Steering wheel turns, lock-to-lock 2.57
Turning circle diameter, curb-to-curb (m) 10.6
Suspension 4-wheel independent
- Front MacPherson strut with stabilizer bar
- Rear Multilink with stabilizer bar

Curb weight (kg) 1,367 (MT)/1,406 (AT)
Fuel capacity (liters) 49.9

Dual-zone automatic climate control with pollen filter
Power windows with driver's one-touch-down/up feature
Power door locks with 2-stage unlocking feature
Cruise control with steering-wheel-mounted controls
Mazda Advanced Keyless Entry
Push button start
Tilt & telescopic steering column
Manual day/night rearview mirror
Rear window defogger with timer

Front center console armrest with covered storage
Dual front cup holders
Front door storage pockets with bottle holders
Front passenger-side seatback pocket
Rear center armrest with cup holders
Rear door bottle holders
Overhead console with sunglasses holder

5-passenger seating capacity
6-way power adjustable driver's seat with manual lumbar adjustment
Variable heated front seats
60/40 split fold-down rear seatback
Perforated leather-trimmed sport seats
Carpet floor mats
Leather-wrapped steering wheel and shifter

7" full-color touch screen display
Bose® 9 speaker surround sound system with Centerpoint® and AudioPilot®
Bluetooth® hands-free phone and audio streaming capability

MAZDA CONNECT™ Infotainment System
- Multifunction Commander Control
- Infotainment system voice command
- Radio Broadcast Data System program information
- Aha™ internet radio integration
- Stitcher™ internet radio integration
- HD Radio™
- Pandora® internet radio integration
- SMS text message audio delivery and reply

Auxiliary-audio input jack
USB Audio input, 2 in front center console
Steering wheel-mounted audio controls

Full-color active driving display
Dual trip odometer
Trip computer

Bi-LED headlights with auto leveling
Automatic on/off headlights
LED fog lights
LED Daytime Running Lights
LED combination taillights
Rain-sensing variable-intermittent windshield wipers
Body-colored power and heated side mirrors with integrated turn signals
Power sliding-glass moonroof with one-touch-open feature and interior sunshade
Roof-mounted "shark fin" antenna
Rear window wiper
Rear roof spoiler

45.72 x 17.78 centimeter aluminum alloy with Dark Silver finish
P215/45 R18 all-season tires
Temporary spare tire - T125/70 D16

Wheelbase (mm) 2,700
Track, front (mm) 1,554
Track, rear (mm) 1,560
Length (mm) 4,580
Width (mm) 1,796
Height (mm) 1,455
Minimum ground clearance, unladen (mm) 155
